1. Summary:
The machine plays a vital role in the sub-prime metalized film capacitors spray process. Its primary purpose is to ensure effective packaging using pressure-sensitive adhesive tape. This preventive measure prevents the occurrence of capacitance issues due to sub-prime short-circuits or damage during the spraying process. After the spraying is completed, the protective tape can be effortlessly removed without causing any harm to the sub-prime capacitors. This approach not only saves time and effort but also contributes to achieving positive economic outcomes.
2. Features:
1. Tight Wrapping: Incorporates the latest packaging technology to address the issue of inadequate package tightness.
2. Higher Efficiency: Designed with an optimized cam mechanism, ensuring low noise levels and high operational efficiency.
3. Larger Tray Capacity: Accommodates trays with a maximum diameter of up to 650mm.
4. Regulation Accuracy: Equipped with multidirectional knobs for precise and reliable positioning adjustments.
5. Space-Saving Design: Offers a back-feed mechanism that conserves space.
6. Perfect Receipts: Effectively eliminates concerns such as large capacitor winding material spillage or loose configurations.
| Applicable subprime machine body size range | |
|---|---|
| Side length | Standard vibration plate mm |
| W (Long) | 20.0-55.0 mm |
| H (High) | 15.0-45.0 mm |
| T (Thick) | 8.0-30.0 mm |
| Specifications | |
|---|---|
| Packing capacity | 2,000-4,000 pcs/hour (depend on different element type) |
| Packing mode | Ω-type packing with tape |
| Management ability | Each operator could manage 5 machines |
| Raw tape plate size | Outside diameter: max. 220mm, Inside diameter: 76mm |
| Finished products | Outside diameter: max. 650mm, Inside diameter: 76mm |
| Power | AC 220V, 50/60HZ , 2KVA |
| Weight | 500KG |
| Machine dimensions | 1750LX1400WX1750H (mm) |
